Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P6.67 P8 P10 Outdoor Led Screen

Name: Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P667 P8 P10 Outdoor Led Screen
Brand: OEM/ODM
Price: 1 USD

Cheap Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P6.67 P8 P10 Outdoor Led Screen for sale

warranty : 5 years

type : LED

Brand Name : OEM/ODM

application : Outdoor

use : advertising publish, retail store, shopping mall, welcome display, self-service business, exhibition hall, wayfinding, airport, subway, elevator, Education, medical treatment

media available : Photo, EDA/CAD Models, datasheet

Model Number : FO series

Place of Origin : Guangdong, China

pixels : Other

Pixel Pitch : 10 mm

Module size : 320*160mm

Usage : Outdoor HD

Cabinet material : Aluminum Module

Cabinet Weight : 40KG/m²

Refresh rate : 3840Hz

Control system : Novastar System

Maintenance mode : Front or rear maintenance

Product name : Outdoor Led Screen

Certificate : CE ROHS FCC CCC ISO9001

Contact Now

标题

Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P6.67 P8 P10 Outdoor Led Screen

Discover Your Right Application , Make Your Business Possible !

Common warranty in LED field is 2 years, ours is 3 years Longer warranty periods, better after-sale services, worry-free user experience

Products Description

Specifications

Model	P3	P3.91	P4	P5	P6	P8	P10
Module size(mm)	320×160	250x250	320×160	320×160	192×192	320×160	320×160
Module resolution (dot)	64×64	64×65	80×40	64×32	32×32	40×20	32×16
Scanning	1/16S	1/17S	1/20S	1/8S	1/8S	1/5S	1/2S
SMD	1G1R1B	1G1R2B	1G1R1B	1G1R1B	1G1R1B	1G1R1B	1G1R1B
Maintenance	Back	Back	Back	Back	Back	Back	Back
Installation	Back	Back	Back	Back	Back	Back	Back
Cabinet size(mm)	960×960	1000×1000	960×960	960×960	960×960	960×960	960×960
Density(dot/㎡)	111111	65410	62500	40000	27777	15625	10000
Brightness(cd/㎡)	4200-4500	4200-4501	5000-6500	5000-6000	5000-6000	4000-5000	6000-7500
Max. Power Consumption	1000	1001	900	800	800	800	1000
Average Power Consumption	350	351	300	400	300	300	500
Cabinet weight (kg/m²)	40kg	41kg	40kg	40kg	40kg	40kg	40kg
Cabinet material	Iron	Iron	Iron	Iron	Iron	Iron	Iron
IP rate	IP 65	IP 66	IP 65	IP 65	IP 65	IP 65	IP 65
Grayscale	10000:1	10000:2	10000:1	10000:1	10000:1	10000:1	10000:1
Refresh rate(hz)	1920-3840	1920-3841	1920-3840	1920-3840	1920-3840	1920-3840	1920-3840
Frame change frequency	50/60hz	50/61hz	50/60hz	50/60hz	50/60hz	50/60hz	50/60hz
Horizontal viewing angle	>140°	>141°	>140°	>140°	>140°	>140°	>140°
Vertical viewing angle	>140°	>141°	>140°	>140°	>140°	>140°	>140°
Best viewing distance	>3m	>4m	>4m	>5m	>6m	>8m	>10m
Input Voltage	AC110V – AC220V	AC110V – AC221V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V
Module Max. current	4.5-5.5	4.5-5.6	5.5-7.5	5.5-7.5	3.5-5.5	5.5-7.0	8.0-10
Temperature-operating	﹣10℃～60℃	﹣10℃～61℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃
Humidity-operating	10%～90%	10%～91%	10%～90%	10%～90%	10%～90%	10%～90%	10%～90%
Life span (H)	≥100,000	≥100,001	≥100,000	≥100,000	≥100,000	≥100,000	≥100,000
MTBF (H)	>10,000	>10,001	>10,000	>10,000	>10,000	>10,000	>10,000

Company Profile

About Us

Shenzhen DDW Technology Co, Ltd is a professional manufacturer and developer of LED display screens in Shenzhen, China since 2012. DDW Display focus on providing indoor outdoor creative LED screen, LED poster, Rental LED screen,Ultra fine HD LED screen,Flexible LED Display,Transparent LED display and various of LED display screens. We are always committed to providing high-quality hardware and software, our excellent pre-sales and after-sales service, and win-win cooperation for all customers.
